Niet alleen voor beginners is een overzicht van primaire componenten en hoe ze moeten worden aangesloten handig. We hebben ook een overzicht van modules.
- Weerstanden
|
|---|
- Werking
Weerstanden werken als een soort electronische wegversmalling.
|
- Diodes
|
|---|
- Werking
Diodes werken als een soort electronisch ventiel. Een engelstalige uitleg op the electronics club. De meest gestelde vraag over diodes is hoe ze moeten worden aangesloten, want diodes hebben een polariteit. Voor een juiste werking moeten ze dus in de juiste richting worden aangesloten. zie ook LED en RGBLed.
|
