Geda is een groep van programma’s om electronische schakelingen en printplaten te ontwerpen. Vanuit de homepage kunt u een engelstalige Wiki openen om u op gang te helpen. Onder Ubuntu kan Geda worden geïnstalleerd vauit het Ubuntu Softwarecentrum door te filteren op geda. Met yum kan het ook worden geïnstalleerd. Er bestaat een uitstekende tutorial om uw eerste print te ontwerpen.
Voordat je kan beginnen moet je een directory structuur aanmaken. Ik adviseer om de directorystructuur te nemen zoals in de tutorial. Ik heb overigens geen subdirectory gschem-sym/transistors gemaakt. Deze directories moeten in de configuratiebestanden van Geda worden opgeslagen zodat het systeem ze in het vervolg kan vinden. Vervolgens wordt de tutorial enigzins vaag, maar het komt er op neer dat je onder Ubuntu een terminal moet openen en met cd /etc/gEDA naar de configuratie map gaat van Geda. Doe in deze map een sudo gedit system-gafrc en voeg aan het einde toe: (component-library "${HOME}/gaf/gschem-sym"). Indien je de submap gschem-sym/transistors wel hebben aangemaakt dan moet je deze ook toevoegen met: (component-library "${HOME}/gaf/gschem-sym/transistors"). Vervolgens gedit opslaan en sluiten. Voeg dezelde regel(s) toe aan: sudo gedit system-gnetlistrc. Nu zijn de juiste verwijzingen gemaakt. Als je wilt kan je nog met sudo gedit system-gschemrc de achtergrondkleur wijzigen van zwart in grijs. Nu is Geda klaar voor gebruik.
